BCH-1t/2t/3t/5t韩国BONGSHIN称重传感器



MODEL BCCU
10, 20, 30, 50t
Rated output(R.O.) 1.5mV/V ± 0.1%
Non-linearity ≤0.02% R.O.
Hysteresis ≤0.02% R.O.
Non-repeatability ≤0.02% R.O.
Creep error ≤0.02% in 20min.
Zero balance ≤1% R.O.
Compensated temperature range -10 ~ 70°C
Operating temperature range -20 ~ 80°C
Temp. effect on rated output ≤0.02% LOAD/10°C
Temp. effect on zero balance ≤0.02% R.O./10°C
Terminal input resistance 350 Ohms ± 3.5 Ohms
Terminal output resistance 350 Ohms ± 5 Ohms
Insulation resistance (Min.) 2000 MOhms at 50V DC
Excitation voltage 10V(Recommended), 15V(Max.)
Electrial connection
Ultimate overload 300% R.C
Rated capacity (R.C.)
Ø9mmx5m(22AWG x 4Core Shielded)
Safe overload 150% R.C

Protection class meets IP 67
