FEMTO低噪声信号放大器用于信号恢复

￥2000.00

广东深圳

深圳市博纳德精密仪器有限公司

12年

指数：250

工商已认证

店铺推荐

图文详情
产品参数

FEMTO®低噪声放大器是*佳选择，因为它们的噪声真的很低。它的名字说明了一切——飞秒 = 10^15 。FEMTO有的放大器的噪声水平达到或低于这个水平。!如果正在为您的信号恢复应用寻找*佳放大器，那么不妨看看 FEMTO放大器。

型号	带宽	增益	输入噪声/特性
DHPCA-100	200.00 MHz	100 to 1x10^8	200 pA/Hz^1/2 to 55 pA/Hz^1/2
DLPCA-200	500.00 kHz	1x10^3 to 1x10^11	4.3 fA/Hz^1/2
HCA-100M-50K-C	100.00 MHz	5x10^4	4.0 pA/Hz^1/2
HCA-10M-100K	10.00 MHz
HCA-10M-100K-C	10.00 MHz	1x10^5	3.5 pA/Hz^1/2
HCA-1M-1M	1.00 MHz	1x10^6	270 fA/Hz^1/2
HCA-1M-1M-C	1.00 MHz	1x10^6	3.5 pA/Hz^1/2
HCA-200M-20K-C	200.00 MHz	2x10^4	4.5 pA/Hz^1/2
HCA-20M-100K-C	20.00 MHz	1x10^5	3.5 pA/Hz^1/2
HCA-2M-1M	2.00 MHz	1x10^6	340 fA/Hz^1/2
HCA-2M-1M-C	2.00 MHz	1x10^6	3.5 pA/Hz^1/2
HCA-40M-100K-C	40.00 MHz	1x10^5	3.7 pA/Hz^1/2
HCA-4M-500K	4.00 MHz	5x10^5	490 fA/Hz^1/2
HCA-4M-500K-C	4.00 MHz	5x10^5	3.5 pA/Hz^1/2
LCA-100K-50M	100.00 kHz	5x10^7	30 fA/Hz^1/2
LCA-10K-500M	10.00 kHz	5x10^8	10 fA/Hz^1/2
LCA-1-10T	1.00 Hz	1 x 10^13	0.18 fA/Hz^1/2
LCA-1K-5G	1.00 kHz	5x10^9	3 fA/Hz^1/2
LCA-200-100G	200.00 Hz	1x10^11	1.5 fA/Hz^1/2
LCA-200-10G	200.00 Hz	1x10^10	1.5 fA/Hz^1/2
LCA-200K-20M	200.00 kHz	2x10^7	40 fA/Hz^1/2
LCA-20K-200M	20.00 kHz	2x10^8	14 fA/Hz^1/2
LCA-2K-2G	2.00 kHz	2x10^9	4.5 fA/Hz^1/2
LCA-30-1T	30.00 Hz	1x10^12	0.5 fA/Hz^1/2
LCA-30-200G	30.00 Hz	2x10^11	0.5 fA/Hz^1/2
LCA-400K-10M	400.00 kHz	1x10^7	65 fA/Hz^1/2
LCA-40K-100M	40.00 kHz	1x10^8	19 fA/Hz^1/2
LCA-4K-1G	4.00 kHz	1x10^9	6.5 fA/Hz^1/2
LIA-BV-150-H	50.00 Hz ~ 120.00 kHz	N/A	4.5 nV/vHz (typ.), 6 nV/vHz (max) voltage noise, 100 dB or greater dynamic reserve
LIA-BV-150-L	5.00 Hz ~ 10.00 kHz	N/A	60 dB dynamic reserve with 100 usec ~ 30 sec time constant
LIA-BVD-150-H	50.00 Hz ~ 120.00 kHz	N/A	25nV/vHz (typ. at 1kHz) voltage noise, 60dB (max) dynamic reserve with 10 msec time constant
LIA-BVD-150-L	5.00 Hz ~ 10.00 kHz	N/A	80 dB dynamic reserve with 300 usec ~ 1 sec time constant
LIA-MV-150-D	10.00 Hz ~ 45.00 kHz	N/A	100 dB to 10 kHz, decreasing by 6 dB/oct above 10 kHz voltage noise, 10 usec dynamic reserve
LIA-MV-150-S	10.00 Hz ~ 45.00 kHz	N/A	100 dB to 10 kHz, decreasing by 6 dB/oct above 10 kHz voltage noise, 10 usec dynamic reserve
LIA-MV-200-H	50.00 Hz ~ 120.00 kHz	N/A	Less than 5nV/vHz (at 1kHz) voltage noise, Maximum 60dB dynamic reserve with 10 msec time constant
LIA-MV-200-L	5.00 Hz ~ 10.00 kHz	N/A	80 dB dynamic reserve with 3 msec ~ 10 sec time constant
LIA-MVD-200-H	50.00 Hz ~ 120.00 kHz	N/A	>100 dB dynamic reserve
LIA-MVD-200-L	5.00 Hz ~ 10.00 kHz	N/A	80 dB dynamic reserve with 300 usec ~ 1 sec time constant
PS-15-3-L	N/A	N/A	Power Supply

品牌：	FEMTO
型号：	FEMTO
加工定制：	否
测量范围：	见详情
测量精度：	见详情
