浩瀚色谱（山东）应用技术开发有限公司研制工作场所空气中邻苯二甲酸酐测定方法：
 空气中邻苯二甲酸酐用玻璃纤维滤纸采集,随即放入预先装有2 ml丙酮的样品瓶中,盖塞,摇匀后用2m×4mm，聚丁二酸乙醇酯:磷酸:101 硅烷化白色担体 = 5:1.5:100； 柱气相色谱(FID)测定。邻苯二甲酸酐浓度在0~210μg/ml范围内线性关系良好,线性方程y=8.95+12.8x(r=0.999 8。


GBZ/T 160.60-2004 工作场所空气有毒物质测定 酸酐类化合物

本标准被GBZ/T 300.118-2017 工作场所空气有毒物质测定 18部分：乙酸酐、马来酸酐 和邻苯二甲酸酐代替

本标准规定了监测工作场所空气中酸酐类化合物浓度的方法。

本标准适用于工作场所空气中酸酐类化合物浓度的测定。



色谱柱：2m×4mm，聚丁二酸乙醇酯:磷酸:101 硅烷化白色担体 = 5:1.5:100；

b) 柱温：175℃；

c) 气化室温度：220℃；

d) 检测室温度：220℃；

e) 载气(氮)流量：25mL/min。





适用于：

安捷伦490在线/便携，4890,5890,6890,7820,7890,8860,8890

岛津GC-14C，GC-2010，GC-2014，GC-2030

赛默飞1310,1300,1610,1600

瓦里安3800系列

布鲁克PE580,590,680,690

磐诺A90，福立GC9790，华爱，天瑞，天美，GC7900，川仪，北分瑞利，东西电子，鲁南瑞虹，捷岛/科晓

Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. has developed a method for determining phthalic anhydride in workplace air
Phthalic anhydride in the air was collected using glass fiber filter paper, and then placed into a sample bottle pre filled with 2 ml of acetone. The bottle was capped and shaken well. Then, a 2m × 4mm mixture of polyethylene succinate: phosphoric acid: 101 silanized white support was used, with a ratio of 5:1.5:100; Column gas chromatography (FID) determination. The linear relationship of phthalic anhydride concentration is good within the range of 0-210 μ g/ml, and the linear equation is y=8.95+12.8x (r=0.999 8).
GBZ/T 160.60-2004 Determination of Toxic Substances in Workplace Air - Anhydride Compounds
This standard is replaced by GBZ/T 300.118-2017 Determination of Toxic Substances in Workplace Air Part 18: Acetic Anhydride, Maleic Anhydride, and Phthalic Anhydride
This standard specifies the method for monitoring the concentration of anhydride compounds in the air of the workplace.
This standard is applicable to the determination of the concentration of anhydride compounds in the air of the workplace.
Chromatography column: 2m × 4mm, poly (ethyl succinate): phosphoric acid: 101 silanized white support=5:1.5:100;
b) Column temperature: 175 ℃;
c) Gasification chamber temperature: 220 ℃;
d) Testing room temperature: 220 ℃;
e) Carrier gas (nitrogen) flow rate: 25mL/min.
Suitable for:
Agilent 490 online/portable, 48905890689088608890
Shimadzu GC-14C, GC-2010, GC-2014, GC-2030
Thermo Fisher Scientific 1310130016101600
Varian 3800 Series
Brooke PE580590680690
Panno A90, Fuli GC9790, Huaai, Tianrui, Tianmei, GC7900， Chuanyi, Beifen Ruili, Dongxi Electronics, Lunan Ruihong, Jiedao/Kexiao
